5 Wire Management Board

5 Wire Management Board


3-5 Business Days Processing Time On All Orders
Need it sooner?
Contact our sales team (260)426-1565!


Replacement for Part #(s): N/A



The 5W Wire Management Board is useful in systems using 5-Wire Digital Control Stations or multiple relay and/or dimmer panels. This product manages the RS-485 wires, allowing a neat and clean connection to a System Master Controller. The 5W Wire Management Board mounts via DIN Rail and can be assembled as part of a system or sold separately. Each unit is equipped with two RJ-45 terminals and four additional spring clamp terminals for control wires.

Touch-Plate Model #: WMB-X5-XX


Mounts via DIN Rail


Includes two RJ-45 terminals and 4 additional spring clamp terminals for RS485 wires

Common Applications

Wire Management in Time-Keeper or similar control panels


Sales Sheets:

Technical Documents:

Engraving Templates:

Touch-Plate's Guaranteed Service

Your System Feeling Stuck?

Need help troubleshooting your Touch-Plate system? We have documentation for all of Touch-Plate’s Products Online.  Check out  ‘Technical Support’ from the main menu!

Would you rather work with someone directly?  You can email questions & pictures to [email protected] and a team member will respond to you as quickly as possible.

You can also give us a call during our regular business hours at (260)426-1565.   We look forward to helping you get the lights back on!

Related Products

Product Specifications

Manufacturing Information:

Manufacturer: Touch-Plate
Product SKU #: WMB-X5-XX
Direct Replacement for Part #(s): N/A

Product Details:

Product Type: Wire Management Board
Operational Environment: Non-condensing atmosphere
Product Material: Black Rynite
# of Relays: N/A

Product Dimensions:

Height: 4.75 in.
Width: 2 in.
Weight: 0.2 lbs
Depth: 1.5 in.
Diameter: -

Technical Information:

Coil Power: N/A
Coil Max Temperature: N/A °F
Wire Type(s): RS485
Coil Resistance: N/A
Protocol: RS485 Network
Auxiliary Contact Configuration: N/A
Latching/Switching: • N/A
Power Input: • 24VAC
Power Output: • 24VAC
Compatible Products: • 5-Wire Time-Keeper Controller
• Smart switches on the RS485 network
