Nexus BACnet Lighting Controller

Save or Share This Page

Facebook Twitter Youtube Envelope Envelope Share-alt

Nexus BACnet Lighting Controller

SKU: NEX-MB-XX

3-5 Business Days Processing Time On All Orders
Need it sooner?
Contact our sales team (260)426-1565!

$587.50/ea

BACnet Controller
Replacement for Part #(s): -

Overview

Documentation

The Nexus BACnet lighting controller offers flexible lighting control for almost any BACnet lighting system. This BACnet controller is able to be integrated with Touch-Plate switches, stations, sensors, relay panels, and dimmer panels. By connecting directly via BACnet MSTP, the Nexus is a key element in adding lighting control to an automated system.
Here are links to some helpful videos for this system
Nexus Controller Overview Nexus System Wiring Overview

Touch-Plate Model #: NEX-MB-XX

Features

All objects are exposed via BACnet
Compatible with many Touchplate relay/dimmer panels

Benefits

Direct BACnet connections via MSTP
Built in soft-patching for lighting control

Common Applications

Commercial applications that have a BAS system that communicates via BACnet/MSTP

Documentation

Sales Sheets:

Nexus BACnet Sales Sheet
Nexus BACnet Sales Sheet
Nexus BACnet PIC Sheet
Nexus BACnet PIC Sheet
Calypso Prime with Nexus BACnet
Calypso Prime with Nexus BACnet

Technical Documents:

Nexus BACnet Manual
Nexus BACnet Manual
Wiring Specifications
Wiring Specifications

Engraving Templates:

None Available
None Available

Touch-Plate's Guaranteed Service

Your System Feeling Stuck?

Need help troubleshooting your Touch-Plate system? We have documentation for all of Touch-Plate’s Products Online.  Check out  ‘Technical Support’ from the main menu!

Would you rather work with someone directly?  You can email questions & pictures to [email protected] and a team member will respond to you as quickly as possible.

You can also give us a call during our regular business hours at (260)426-1565.   We look forward to helping you get the lights back on!

Product Spotlight

Play Video

Product Specifications

Manufacturing Information:

Manufacturer: Touch-Plate
Product SKU #: NEX-MB-XX
Direct Replacement for Part #(s): -

Product Details:

Product Type: Nexus BACnet Controller
Operational Environment: Non-condensing atmosphere
Product Material: -
# of Relays: -

Product Dimensions:

Height: 6.562 in.
Width: 3.313 in.
Weight: 0.5 lbs
Depth: 1.5 in.
Diameter: -

Technical Information:

Coil Power: -
Coil Max Temperature: -
Wire Type(s): RS485
Coil Resistance: -
Protocol: BACnet Protocol
Auxiliary Contact Configuration: -
Latching/Switching: -
Power Input: • 24VDC
Power Output: -
Compatible Products: • BACnet systems
• Many Touchplate relay and dimmer panels
