TPS-0120 Power Supply | 120V Replacement Transverter

Save or Share This Page

Facebook Twitter Youtube Envelope Envelope Share-alt

TPS-0120 Power Supply | 120V Replacement Transverter

This product can also be purchased on Amazon

Amazon Store
Amazon Store

SKU: TPS-0120

3-5 Business Days Processing Time On All Orders
Need it sooner?
Contact our sales team (260)426-1565!

$106.50/ea

This IS NOT a replacement for the PL-6 pilot light transformer.
Replacement for Part #(s): TVR-1 or 78K1 / 17C

Overview

Documentation

The TPS-0120 Power Supply (Transverter) is a replacement 120V power supply for Touch-Plate Low-voltage Lighting Systems installed between 1946-1985.

Touch-Plate Model #: TPS-0120

Features

Direct replacement for the TVR-1 or 78K1 / 17C
Primary voltage: 120VAC @ 20ma Input
Secondary Voltage: 28.5 VDC at 28ma (0.028amp) Output

Benefits

1.2 VA Class 2

Common Applications

Touchplate Legacy Systems installed between 1946-1985

Documentation

Sales Sheets:

TPS-0120 Transverter Sales Sheet
TPS-0120 Transverter Sales Sheet

Technical Documents:

Low-voltage Wiring Diagram
Low-voltage Wiring Diagram
Stuck Switch Troubleshooting Guide
Stuck Switch Troubleshooting Guide
Frequently Asked Questions - Technical Guide
Frequently Asked Questions - Technical Guide

Engraving Templates:

None Available
None Available

Touch-Plate's Guaranteed Service

Your System Feeling Stuck?

Need help troubleshooting your Touch-Plate system? We have documentation for all of Touch-Plate’s Products Online.  Check out  ‘Technical Support’ from the main menu!

Would you rather work with someone directly?  You can email questions & pictures to [email protected] and a team member will respond to you as quickly as possible.

You can also give us a call during our regular business hours at (260)426-1565.   We look forward to helping you get the lights back on!

Related Products

Related products

Product Specifications

Manufacturing Information:

Manufacturer: Touch-Plate
Product SKU #: TPS-0120
Direct Replacement for Part #(s): TVR-1 or 78K1 / 17C

Product Details:

Product Type: Replacement Transverter
Operational Environment: Max Operating temp of 65 degrees Celcius
Product Material: Black Rynite Plastic Case
# of Relays: Can power multiple relay panels

Product Dimensions:

Height: 1.875 in.
Width: 3.3125 in.
Weight: 0.6 pds lbs
Depth: 2.75 in.
Diameter: -

Technical Information:

Coil Power: N/A
Coil Max Temperature: N/A °F
Wire Type(s): Low Voltage Output - 18-22 AWG
Coil Resistance: N/A
Protocol: Analog
Auxiliary Contact Configuration: N/A
Latching/Switching: • N/A
Power Input: • 120VAC @ 20ma Power Requirement
Power Output: • 28.5 VDC at 28ma (0.028amp) Output
Compatible Products: • Model 3000 Relays
• Touchplate Analog Contact Closure Switches
