Soluxe Universal 24 Relay Panel

DMX
Soluxe Universal 24 Relay Panel

SKU: SLXUD-XX120-24RP

3-5 Business Days Processing Time On All Orders
Need it sooner?
Contact our sales team (260)426-1565!

$3,037.80/ea

Requires a front end controller to operate and digital 5-wire switches for local control.
Replacement for Part #(s): -

Product Spotlight

Play Video

Overview

Documentation

The Soluxe Universal relay panel is a single-board solution, including the control of 8 relays per board. It is DMX-ready, requiring only a connection to the appropriate front-end controller. The Soluxe Universal is perfect for a wide range of applications due to its small footprint and versatility. Apart from applications requiring specific protocols, the Soluxe Universal requires a Touch-Plate Master Controller to perform.

Touch-Plate Model #: SLXUD-XX120-24RP

Features

Direct DMX connection via a controller that communicates on a RS-485 network using the 512 protocol.
Electronically held relays
Comes with relay board, enclosure and transformer.
Can combine Soluxe Universal Relays and Solare Universal Dimmers in one panel - Contact us for ordering.

Benefits

Full programmable with appropriate front end controller.
Can be used with digital 5-wire switch stations.
277V Available - Contact us for ordering.
Available in a Modbus version - Contact us for ordering.

Common Applications

Commercial applications that have a DMX controller that communicates on a RS-485 network
Residential applications that have a Time-Keeper MAX controller or a another DMX controller that communicates on a RS-485 network
This product is compatible with Touch-Plate's TimeKeeper Master Controllers. Click below to learn more.

Documentation

Sales Sheets:

Technical Documents:

Engraving Templates:

Touch-Plate's Guaranteed Service

Your System Feeling Stuck?

Need help troubleshooting your Touch-Plate system? We have documentation for all of Touch-Plate’s Products Online.  Check out  ‘Technical Support’ from the main menu!

Would you rather work with someone directly?  You can email questions & pictures to [email protected] and a team member will respond to you as quickly as possible.

You can also give us a call during our regular business hours at (260)426-1565.   We look forward to helping you get the lights back on!

Related Products

Product Specifications

Manufacturing Information:

Manufacturer: Touch-Plate
Product SKU #: SLXUD-XX120-24RP
Direct Replacement for Part #(s): -

Panel Details:

Product Type: Programmable Relay Panel
Operational Environment: 0 - 60C (0 - 140F) non-condensing atmosphere
# of Relays: 24-Relay
Product Material: Board: Black Rynite
Enclosure Type: Powder Coated White; U.S. Gauge Steel

Panel Dimensions:

Height: 34.25 in.
Width: 14.25 in.
Weight: 38 lbs
Depth: 3.75 in.
Diameter: -

Technical Information:

Wire Type(s): 24 AWG, 2PR, Shielded
Dimmer Wattage: -
Load Compatibility: • Incandescent
• Fluorescent
• LED
• Magnetic Low Voltage
• Electronic Low Voltage
Power Input: • 120VAC feed into Transformer
Compatible Products: • Touch-plate Digital 5-Wire Switches
• Time-Keeper MAX programmable controller
• Other DMX Controllers using the 512 Protocol.
